All Plans

JEPLANS.COM

Woodworking and Scroll Saw projects and plans for everything from Engines to Toys.

Note: Plans are provided as a downloadable PDF files.
Whenever possible my plans are designed to be attached directly to the material you are working on.

All purchased plans are downloadable from www.jeplans.com once your purchase is complete. Simply Login and click "Member Area / Downloads".
If you any issues please Contact Us

Easter Bunny Nutcracker
Pic:

Easter Bunny Nutcracker

This compound scrolling project is assembled in multiple compound cut parts. To achieve wonderful nutcrackery results.

I highly recommend this project for anyone who likes 3D scroll projects and Nutcrackers.

See Video!

$6.00
Blade Knob Adapter
Pic:

Blade Knob Adapter

for the DeWALT DW788 20in Scroll Saw An Adapter to make the removal and installation of blades easier.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Paper Towel Holder 1
Pic:

Paper Towel Holder

Plans for a wall mount vertical Paper Towel Holder with a little compound scrolling it give it some character .

$2.00
Cordless Drill Holder1
Pic:

Drill Holder

This Cordless Drill Holder is designed to fit a DeWALT DCD760 18 Volt Drill, But may work with other models.
Simply apply pattern to wood, cut out and glue together. Design is for 3/8” plywood.

Enjoy, James Eckert

$0.00 (FREE!)
DOWNLOAD PLAN!!
Sharpie Holder Mount 2
Pic:

Sharpie Holder Mount

Plans For: Wall Mount for Sharpie Carousel. Sharpie Carousel Available at: https://www.thingiverse.com/thing:5153430

$0.00 (FREE!)
DOWNLOAD PLAN!!
Garden Hose Holder
Pic:

Garden Hose Holder

Hose Holder is a Quick easy Project made for 1/4" material. Mine was made from a sheet of PVC. Note: Lion Head is not part of plan, it is available at: https://www.thingiverse.com/thing:4867817

$2.00
CSElephant
Pic:

3D Elephant

Compound Scrolling Pattern for a Elephant. It is challenge to cut out and shape. Tools: Scroll Saw, Drill Press, Rotary Tool.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Small shelf
Pic:

Small Shelf

This Free Scroll Saw Plan is a quick and easy to build small shelf for the workshop or anywhere you might need one.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Glasses holder1
Pic:

Safety Glasses Wall Mount

Wall Mount for my Cheaters and Safety Glasses/n Note: STL for 3d printing

$0.00 (FREE!)
DOWNLOAD PLAN!!
doll table 18 inch1
Pic:

Doll Table

These plans are is sized for 18 inch dolls to sit at.
It is about 8 1/2 inches tall by 8 1/2 inches square.

My niece loved finished product.

See Video!

$4.50
Scroll Saw Camel
Pic:

3D Camel

Compound Scrolling Pattern for a Camel. Plans have both a scroll saw pattern and an untested band saw pattern.

See Video!

$3.50
Scroll Saw Nut Cracker 1
Pic:

Scroll Saw Nutcracker

I have always wanted to make a Scroll Saw Nut Cracker and here it is. This is a compound scrolling project where you cut several parts and assemble them into something wonderful. I highly recommend this project for anyone who likes 3D scroll projects and Nutcrackers.

See Video!

$6.00
Retro Speaker
Pic:

Mini Vintage Speaker Box

This design is fro a speaker enclosure designed to mimic a 1930s style speaker. It is sized to fit a 2.25" speaker.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Pagoda Lantern 1
Pic:

Pagoda Lantern

A Fine Scroll Saw Pagoda Lantern. This plan contains many angle cuts to produce a very rewarding result.

See Video!

$9.00
Capacitance Touch Pad
Pic:

Capacitance Touch Pad

Pattern for Capacitance Touch Pad for the MPR121 Capacitive Touch Sensor Module. This pattern is provided as and does not contain instruction on making the touch pad. See Linked video for how I made it.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
3D Print Steam Whistle1
Pic:

Steam Whistle

The is a 3D print version of my Wood Steam Whistle design. View the YouTube Video to see it in action.

Purchase includes stl files for 3D Printing yourself, Not the printed Item.

See Video!

$1.00
Wood Steam Whistle
Pic:

Wood Steam Whistle

This scroll saw project is a wooden whistle designed in the style of a steam whistle. It is a fairly quick and satisfying project that uses simple angled cuts to achieve complex results. Of course the whistle is not intended for use with steam.

See Video!

$3.75
Simple 3D Printed Whistle
Pic:

Simple Whistle

3D Print Version of my Wooden Whistle

Purchase includes stl files for 3D Printing yourself, Not the printed Item.

$0.00 (FREE!)
DOWNLOAD PLAN!!
DIY Pong Paddles
Pic:

Pong Paddles

Small Paddles I designed for an Arduino Pong game. Plans include patterns for scroll saw and a 3d printed version.

$0.00 (FREE!)
DOWNLOAD PLAN!!
WallTree
Pic:

WallTree

This multilevel wall mount coat rack is sure to turn some heads.

See Video!

$4.50
Bull's Head full size
Pic:

Bull's Head

The Bull's Head is a quick fun scroll saw plan that can be made start to finish in just a couple of hours. Plans have a full size version just under 31 inches wide perfect for hanging on a wall or over a door,and a small version 4.5 inches wide perfect for a refrigerator magnet or toy barn.

$3.50
Gravity Light 1
Pic:

Grav-Light

Platform for kinetic energy conversion and experimentation.This Gravity Light project is very challenging.The focus of the 26 page plan is the gearbox and alternator.
Primary Tools:Scroll Saw ,Drill Press

See Video!

$10.00
ESP8266  Enclosure
Pic:

ESP8266 Enclosure

This Scroll Saw Pattern is an enclosure designed to fit the ESP8266-01 wireless module and a battery holder to for 2 C batteries.
Primary Tools:Scroll Saw ,Drill

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
DHT22 Houseing
Pic:

DHT22 Enclosure

This Enclosure is designed to house the DHT22/AM2302 Temperature and Humidity sensor. While allowing air flow and reducing direct contact with rain and snow.
Primary Tools:Scroll Saw ,Drill

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Chicken water hook
Pic:

Corner Hook

This Scroll Saw Pattern is a great chicken coop space saver. This Corner Hook is design to fit a small hanging chicken water dish.

$0.00 (FREE!)
DOWNLOAD PLAN!!
Chicken Perch 1
Pic:

Chicken Perch

A Quick and Easy to Make Chicken Perch.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Pi Wall Mount 1
Pic:

Wall Mount PI Enclosure

Custom wall mount enclosure for use with the Raspberry Pi B+

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
3d Till-Cash Register
Pic:

3D Till/Cash Register

This Compound Scrolling plan produces a fine Cash Register. It is sized to work with many children's small doll play sets and is quick to make. Finished item is about 1 1/4".
Primary Tools: Scroll Saw, Drill

See Video!

$1.00
Air Boat
Pic:

Bottle Boat Test Platform

Plans for a compressed air bottle boat intended for testing of air engines. This 14 page set of Scoll Saw plans include Boat Platform, Air Hookup and Air Mount, 2 Props, Prop/Rudder Assembly, Cardan shaft/Universal Joint, Mount for Pentabello engine.Engine Plans sold separately
Primary Tools:Scroll Saw, Drill Press

See Video!

$2.00
Games Pieces1
Pic:

Games Pieces Rocket Ship

Compound Scroll Saw Games Pieces

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Zombie Shooter
Pic:

Rubber Band Loom Zombie Shooter

The Rubber Band Loom Zombie Shooter is fun Slingshot and Target Scroll Saw project for whole family. Of course you will need someone to make the rubber band parts.Warning Eye Injury Risk! Never Shoot people or pets with Zombie Shooter(Slingshot).

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Christmas Engine 1
Pic:

Coffee Mug or Christmas Engine

This Christmas themed coffee cup Stirling Engine is whimsical and fun to build. Less skill is required to build this engine than most of my other engines.To make it without rescaling the plans requires a Coffee Mug with straight sides and top inner diameter of about 3".
Primary Tools:Scroll Saw, Drill Press

See Video!

$4.00
Fish Tank Plans
Pic:

Fish Tank

Small Fish Tank Plans. This homemade aquarium is perfect for a small Goldfish or Betta. Size of glass portion about 8" x 5" x 5".
Primary Tools: Scroll Saw, Drill press, Glass cutter

See Video!

$4.00
Hospital Set 3
Pic:

Toy Hospital Set 3

Toy Hospital Set 3, Table, Defibrillator, Stand and tools
This plan set makes a Hospital Table that fits with the Bed in plan set 1 and the Wheel Chair in plan set 2. It also has plans for a Defibrillator, IV Stand, Reflex Hammer and Scalpel.It is quick and fun scroll saw project that is sure to amuse.
Primary Tools:Scroll Saw,Drill

See Video!

$2.00
Toy Wheel Chair and Crutches
Pic:

Toy Hospital Set 2

Toy Hospital Set 2, Wheelchair and Crutches
This plan makes a small Wheelchair and Crutches that is sized nicely to fit smaller stuffed animals. It is quick and fun scroll saw project that is sure to amuse. Wheelchair is about L9" x W6" x H8".
Primary Tools:Scroll Saw,Drill

See Video!

$4.50
Toy Hospital Bed scroll saw project
Pic:

Toy Hospital Set 1

Toy Hospital Set 1, Hospital Bed and Accessories
This plan makes a small bed that is sized nicely to fit smaller stuffed animals. It is quick and fun scroll saw project that is sure to amuse. Finished Bed is 11 3/4" x 6 1/2" and breaks down nicely for storage.
Note: plan does not include mattress pattern.
Primary Tools:Scroll Saw,Drill

See Video!

$3.50
Mini Radial Air Engine Front
Pic:

Mini Radial Air Engine

This small pneumatic engine is built on the piston valve design most of my other air engine use only smaller sharing a piston diameter with the Mini V8. Because of the radial configuration it is easier to build then the V8 but still difficult compared to the larger engines.

See Video!

$6.00
Wooden Helicoptor
Pic:

Wooden Helicopter

This Wooden Helicopter scroll saw project feature an amazing bevel gear drive.
Primary Tools:Scroll Saw,Drill

See Video!

$4.00
3d Table and Lamp
Pic:

3D Table and Lamp

This 3d Table and Lamp is a quick fun scrolling project that makes a fine addition to any doll house.Finished items stand about 3" tall together.
Primary Tools: Scroll Saw, Drill

See Video!

$2.50
 	Pentabellow Rotary Air Engine 1
Pic:

Pentabellow Rotary Air Engine

This odd bellows driven rotary engine is one of a kind. Inspired by early aircraft rotary engines. The entire engine rotates around a central shaft. I love this engine for is uniqueness.
Primary Tools:Scroll Saw, Drill Press

See Video!

$7.00
Mini V8 front top
Pic:

Mini V8 Air Engine

Mini V8 Air Engine. This ultra small V8 engine is a challenge to build because of its size. But the satisfaction is that much greater when you get it running.
Primary Tools:Scroll Saw, Drill Press

See Video!

$8.00
Celtic Wooden Cross Plans
Pic:

Wooden Cross 2

My 2nd Wooden Cross design inspired by Celtic cross designs.
Primary Tools:Scroll Saw, Drill Press

$3.00
Electric Motor
Pic:

Nine Nail Electric Motor

These plans are for my adaptation of a strange electric motor. I came across a drawing and explanation of one in a 1940s magazine. Inspired by that, I had to design and make my own.
Warning Electromagnet gets hot after a few minutes of run time!
Primary Tools:Scroll Saw ,Drill Press

See Video!

$3.50
Wooden Cross
Pic:

Wooden Cross

Weaved appearance Wooden Cross that hangs on the wall.
Primary Tools:Scroll Saw,Drill Press

$3.00
Leprechaun and Pot of Gold
Pic:

Leprechaun and Pot of Gold

This figure is a quick fun project and a perfect decoration for Saint Patrick's Day.
Primary Tools: Scroll Saw

$0.00 (FREE!)
DOWNLOAD PLAN!!
Copper Top Engine
Pic:

Copper Top Engine

The Copper Top Stirling Engine. This is both my simplest and my fastest Stirling engine.
Primary Tools:Scroll Saw, Drill Press , Scissors

See Video!

$3.50
Beer Bottle Engine
Pic:

Beer Bottle Engine

The Original Beer Bottle Engine. This Stirling engine has running on my wood stove every winter since 2010. This Designs draw back is it utilizes an old computer heat sink not everyone will have a substitute for.
Primary Tools:Scroll Saw, Drill Press , Bottle Cutter, Scissors

See Video!

$2.75
Beer Bottle 2 Engine
Pic:

Beer Bottle Engine 2

Beer Bottle 2 Stirling Engine. In this design I merged several proven techniques from earlier designs with some new approaches, to create a very reliable engine. The main new approaches are a wooden support structure, wood air channels and bellows drive system.
Primary Tools:Scroll Saw, Drill Press , Bottle Cutter

See Video!

$6.75
Nautical Chess Set 1
Pic:

Nautical Chess Set

This fun set was inspired by my 3d lighthouse plan. These compound scrolling plans are only the chess pieces not the chess board. The king and queen require a small amount shaping with a carving knife or rotary tool to achieve what is seen in the pictures.
Primary Tools:Scroll Saw, Drill Press

See Video!

$6.50
Fans And Flywheels1
Pic:

Fans and Flywheels

This is a set of patterns for the fans and flywheels seen in many of my videos.
Primary Tools:Scissors, Drill Press, Scroll Saw

See Video!

$2.50
LED Lantern 1
Pic:

Paper LED Lantern

This is a quick fun paper lantern to make. For use with battery powered LED Puck lights. Makes a pretty good camping lantern.
Primary Tools:Scissors , Hobby Knife

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Robot Giraffe
Pic:

Robot Giraffe

Poseable Wooden Robot Giraffe Figure.
It is quick fun project that sure to get a laugh or two.
Primary Tools:Scroll Saw,Drill Press

See Video!

$3.50
Robot Pig
Pic:

Robot Pig

Poseable Wooden Robot Pig Figure.
It is quick fun project that sure to get a laugh or two.
Primary Tools:Scroll Saw,Drill Press

See Video!

$3.50
Dog Robot 1
Pic:

Robot Dog

Poseable Wooden Robot Dog Figure.
It is quick fun project that sure to get a laugh or two.
Primary Tools:Scroll Saw,Drill Press

See Video!

$3.50
Robots 1
Pic:

Robot

Poseable Human form Wooden Robot Doll. They make an excellent desk accessory and office stress reliever.
Primary Tools:Scroll Saw, Clamps ,Drill Press

See Video!

$5.50
Toy Mailbox
Pic:

Toy Mailbox

The Toy Mailbox is a great weekend scroll saw project.
Primary Tools:Scroll Saw,Drill

See Video!

$4.00
Dowel Holder
Pic:

Dowel Holder

A place to put your dowels, what more needs to be said.

$0.00 (FREE!)
DOWNLOAD PLAN!!
Bellows 1
Pic:

Pneumatic Power System 1

Plans for the first version of my bellows and air rectifier, used for demonstration of my air engines.

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
3D Giraffe 2
Pic:

3D Giraffe

Plans include patterns for both compound scrolling on a scroll saw and a larger plan for a band saw. Scroll saw giraffe is about 3" tall, band saw version is 6 3/4" tall. A small amount shaping with a carving knife or rotary tool is needed to achieve what is seen in the pictures.
Primary Tools: Scroll Saw, Band Saw, Drill Press

See Video!

$3.50
Bean
Pic:

Deck Bean Growing Apparatus

Apparatus for growing climbing or pole beans on a deck, patio or balcony. This is a great way to grow climbing beans on your deck. The wind can't blow it over, it's away from pests and you get a lot more beans then a bush type would yield.
Primary Tools: Scroll Saw, Drill

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Fire Safety Pine Cone 1
Pic:

Fire Safety Pine Cone

This is a simple and fun summer project that makes use of a pine cones natural tendency to close when wet and open when dry. Everyone will asking what in the world is that. For entertainment purposes only.
Primary Tools: Scroll Saw, Drill

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Inline 4 Air Engine
Pic:

Inline 4 Cylinder Air Engine

The Inline 4 Cylinder Pneumatic Engine. These plans use the same Piston-Valve design as my Radial air Engine in a different layout. The inline 4 could be doubled for a V8 configuration.
Primary Tools: Band Saw, Scroll Saw, Drill Press

See Video!

$8.00
Pliers Set Holder 1
Pic:

Pliers Set Holder

A quick and easy project that helps keep track of your tools, what more could you want.
Primary Tools: Scroll Saw, Drill

$0.00 (FREE!)
DOWNLOAD PLAN!!
Lighthouse 2
Pic:

Lighthouse

This lighthouse is one of my personal favorites. Make the top by itself and its a toy to use with a children's block set, make more than one or kids fight over it.
Plans include 1 1/2", 1" and block top version.
Primary Tools: Scroll Saw, Drill Press

See Video!

$3.50
Radial Air Engine 1
Pic:

Radial Air Engine

Radial Pneumatic Engine that runs on pressure, vacuum or both. These are the plans for the model engine in my YouTube Video "Rotary Air Engine" or "The Simplified Pneumatic Engine and Power System".
Primary Tools: Band Saw, Scroll Saw, Drill Press

See Video!

$6.50
Stirling Engine Stand 1
Pic:

Stirling Engine Stand

A Stirling engine candle stand. With these plans to you can make a stand to run your engine with a candle or small oil lamp.
Primary Tools: Scroll Saw, Drill Press

See Video!

$2.00
Balance Scale for scroll saw
Pic:

Balance Scale

This balance scale is interesting scroll saw project, which is both pleasing to the eye and functional. Originally built to help with a Stirling engine project, my daughter and I had fun comparing the weight of things from around the house.
Primary Tools: Scroll Saw, Drill Press

See Video!

$4.00
Drying Helper 1
Pic:

Drying Supports

Small Supports to assist in drying freshly finished items.
Tools:Scroll Saw

$0.00 (FREE!)
DOWNLOAD PLAN!!
Cherry Whistle
Pic:

Wooden Whistle

This whistle is a quick simple project that produces surprising results.
Primary Tools:Scroll Saw, Clamps

See Video!

$0.00 (FREE!)
DOWNLOAD PLAN!!
Phoenix Engine Front 1
Pic:

The Phoenix Engine

This well thought out engine works across a wide range of temperatures on a wood stove without stalling. Includes plans for both the Engine and the stand. Plans go along with the 7 part video series on YouTube by James Eckert, Making a Stirling Engine. The plans were developed in lock step with the videos. The intent was to come up with a simple yet interesting to watch Stirling engine made with readily available parts. Now includes custom candle stand.
Primary Tools:Scroll Saw, Drill Press , Bottle Cutter

See Video!

$6.75
wood flute
Pic:

Wooden Flute

The Wooden Flute is a quick Scroll Saw project that really works. It is a blend of my whistle design and a recorder. Plans include 2 versions, one smaller that matches what is depicted in my YouTube Video and one that will closely match a soprano recorder.
Primary Tools:Scroll Saw, Clamps ,Drill Press

See Video!

$4.75

Login to Disable Ads
